TEKA 42W AC/DC adapter

Name: TEKA 42W AC/DC adapter
Brand: TEKA
SKU: TEKA-WM42W

SKUTEKA-WM42W

TEKA AC/DC adapters & power boards · Power, drivers & controls. Specified, quoted and supplied by Project Supplies for commercial projects.

Main output options12V2.5A / 12V3A / 24V1.5A

Input100-240V~ 50/60Hz 1.2A MAX

Output12.0V-2.5A / 12.0V-3.0A / 24.0V-1.5A

Plug typesAU, BS, CH, EU, EAC, JP, US

Price on requestQuoted for your configuration and quantity.

Technical clarificationTranscribed from the supplied TEKA product catalogue (slide 9). Certification marks and ratings are supplier claims; confirm the exact model, plug type and Australian approvals (RCM/SAA where required) before ordering.

Quantity (units)

Your configuration (optional)

Project Supplies specification sheet

Confirm the specification and quotation before ordering.

Product introduction

AC/DC adapters & power boards

Key data: main output options 12V2.5A / 12V3A / 24V1.5A; input 100-240V~ 50/60Hz 1.2A MAX; output 12.0V-2.5A / 12.0V-3.0A / 24.0V-1.5A; plug types AU, BS, CH, EU, EAC, JP, US.

Every order starts with an RFQ: we confirm the exact variant, options, lead time and commercial terms in an itemised quotation before anything is ordered.

Main output options12V2.5A / 12V3A / 24V1.5A

Input100-240V~ 50/60Hz 1.2A MAX

Output12.0V-2.5A / 12.0V-3.0A / 24.0V-1.5A

Plug typesAU, BS, CH, EU, EAC, JP, US

Housing materialPC

Fire rating94 V0

Certification (as published)SAA/RCM/CE/UKCA/CCC/PSE/UL/FCC/EAC/KC

ProtectionsOvercurrent, Short circuit, Lightning/surge, Overvoltage

Specifications

The technical details.

Download specification sheet

Product type: Wall-mount adapter
Main output options: 12V2.5A / 12V3A / 24V1.5A
Input: 100-240V~ 50/60Hz 1.2A MAX
Output: 12.0V-2.5A / 12.0V-3.0A / 24.0V-1.5A
Plug types: AU, BS, CH, EU, EAC, JP, US
Dimensions: Vertical fixed-plug: 32 x 89.5 x 43 mm; Wall-mount (BS plug shown): 50 x 74 x 54 mm; Interchangeable-plug: 39 x 89.5 x 43 mm; Desktop: 97 x 45 x 29.5 mm
Housing material: PC

Fire rating: 94 V0
Certification (as published): SAA/RCM/CE/UKCA/CCC/PSE/UL/FCC/EAC/KC
Protections: Overcurrent, Short circuit, Lightning/surge, Overvoltage
Fixed-plug variants: AU, BS, CH, EU, JP, US
Interchangeable plug heads: AU, BS, CH, EU, EAC, JP, US
Optional AC inlet (desktop version): IEC C14 (3-pin) / IEC C8 (2-pin figure-8) / IEC C6 (3-pin cloverleaf) (inlet types identified from pictured sockets)
Model (label): TEKA-TE120300BS (BS wall-mount variant label; printed 'MODLE')
