LEIPOLELP030-A2Q: Condensate Evaporator 9.6L/D, Enclosure Accessory LP-LP030-A2Q
Enclosure coolingHover to zoom

LEIPOLE · Enclosure cooling

LP030-A2Q: Condensate Evaporator 9.6L/D, Enclosure Accessory

SKULP-LP030-A2Q

LEIPOLE Enclosure cooling · Control panel components. Specified, quoted and supplied by Project Supplies for commercial projects.

Dimensions362 x 130 x 60mm
Nominal voltage220V, 50Hz
Nominal current2.4A
Power500W
Price on requestQuoted for your configuration and quantity.
Technical clarificationSpecifications and certification marks are as published by LEIPOLE Singapore and are not independently verified. Confirm the exact model, ratings and approvals for your switchboard or enclosure before ordering.
Project Supplies specification sheet

Confirm the specification and quotation before ordering.

Product introduction

Enclosure cooling

Key Functions of Enclosure Cooling Units Temperature Regulation : Enclosure AC units maintain a consistent temperature, preventing overheating and ensuring the reliable operation of sensitive equipment. Humidity Control : Many enclosure air conditioners also manage humidity levels, reducing the risk of condensation and corrosion. Dust and Contaminant Protection : By creating a sealed environment, these units prevent dust and debris from entering the enclosure, which can damage electronic components. Benefits of Enclosure Air Conditioners Enhanced Equipment Lifespan : By maintaining a stable temperature, enclosure AC units extend the life of electronic components. Energy Efficiency : Modern ….

Key data: dimensions 362 x 130 x 60mm; nominal voltage 220V, 50Hz; nominal current 2.4A; power 500W.

Every order starts with an RFQ: we confirm the exact variant, options, lead time and commercial terms in an itemised quotation before anything is ordered.

Dimensions362 x 130 x 60mm

Nominal voltage220V, 50Hz

Nominal current2.4A

Power500W

ModelLP030-A2Q

Part NumberLP030-A2Q

Order Code2027.006

Evaporation capacity9.6L/D

Specifications

The technical details.

Download specification sheet
Category
Enclosure cooling
Model
LP030-A2Q
Part Number
LP030-A2Q
Order Code
2027.006
Dimensions
362 x 130 x 60mm
Nominal voltage
220V, 50Hz
Nominal current
2.4A
Power
500W
Evaporation capacity
9.6L/D
Operating temperature
-40~+55 °C RH0-95%
Weight
2Kg

Documents

Specification sheet & source.

Project Supplies specification sheet

LP-LP030-A2Q

Product image, key data, the full specification and document control — laid out for project submittals.

PDF · A4Reviewed 2026-10-06LEIPOLE
Open specification sheet

Technical source

LEIPOLE

Checked 2026-10-06. Manufacturer values are reference specifications; confirm the exact variant and installation requirements before approval.
