LEIPOLELEIPOLE JPTTB 2.5/JPTTB 2.5-BU Feed-through Terminal Block 24A 800V Industrial Wiring LP-JPTTB-2.5/JPTTB-2.5-BU
Terminal blocksHover to zoom

LEIPOLE · Terminal blocks

LEIPOLE JPTTB 2.5/JPTTB 2.5-BU Feed-through Terminal Block 24A 800V Industrial Wiring

SKULP-JPTTB-2.5/JPTTB-2.5-BU

LEIPOLE Terminal blocks · Control panel components. Specified, quoted and supplied by Project Supplies for commercial projects.

CertificationCE, CQC
Zack StripZB5
SizeT5.2×H83.6×W48.7
Rated Current/Rated Voltage24A/800V
Price on requestQuoted for your configuration and quantity.
Technical clarificationSpecifications and certification marks are as published by LEIPOLE Singapore and are not independently verified. Confirm the exact model, ratings and approvals for your switchboard or enclosure before ordering.
Project Supplies specification sheet

Confirm the specification and quotation before ordering.

Product introduction

Terminal blocks

LEIPOLE JPTTB 2.5 and JPTTB 2.5-BU are double-level 4-conductor screw-type feed-through terminal blocks for standard DIN rail mounting. Designed for industrial control and low-voltage distribution wiring, they provide stable multi-wire connections with reliable screw clamping. Insulation and conductive components meet industrial standards for safe and consistent performance in daily industrial environments. Key Features & Advantages Double-level 4-conductor design for high-density wiring Screw connection for stable and reliable wiring UL 94 V0 flame-retardant housing for operational safety Compliant with IEC 60947-7-1 international standards Compatible with NS 35/7.5, NS 35/15 and NS 32 DIN ….

Key data: certification CE, CQC; zack strip ZB5; size T5.2×H83.6×W48.7; rated current/rated voltage 24A/800V.

Every order starts with an RFQ: we confirm the exact variant, options, lead time and commercial terms in an itemised quotation before anything is ordered.

CertificationCE, CQC

Zack StripZB5

SizeT5.2×H83.6×W48.7

Rated Current/Rated Voltage24A/800V

Cross Section0.5~4mm²

ModelJPTTB 2.5/JPTTB 2.5-BU

Flammability ClassUL 94 V0

Connection StandardIEC 60947-7-1

Specifications

The technical details.

Download specification sheet
Category
Terminal block
Model
JPTTB 2.5/JPTTB 2.5-BU
Certification
CE, CQC
Flammability Class
UL 94 V0
Connection Standard
IEC 60947-7-1
Zack Strip
ZB5
Order Number
1012.065/1012.071
Size
T5.2×H83.6×W48.7
Rated Current/Rated Voltage
24A/800V
Cross Section
0.5~4mm²
Din Rail Type
NS 35/7.5, NS 35/15, NS 32

Documents

Specification sheet & source.

Project Supplies specification sheet

LP-JPTTB-2.5/JPTTB-2.5-BU

Product image, key data, the full specification and document control — laid out for project submittals.

PDF · A4Reviewed 2026-10-06LEIPOLE
Open specification sheet

Technical source

LEIPOLE

Checked 2026-10-06. Manufacturer values are reference specifications; confirm the exact variant and installation requirements before approval.
