LEIPOLE JDIK 1.5 Feed-through Terminal Block

Name: LEIPOLE JDIK 1.5 Feed-through Terminal Block
Brand: LEIPOLE
SKU: LP-JDIK-1.5

SKULP-JDIK-1.5

LEIPOLE Terminal blocks · Control panel components. Specified, quoted and supplied by Project Supplies for commercial projects.

CertificationCE, CQC

Zack StripZB5

SizeT6.2×H55.5×W56

Rated Current/Rated Voltage26A/250V

Price on requestQuoted for your configuration and quantity.

Technical clarificationSpecifications and certification marks are as published by LEIPOLE Singapore and are not independently verified. Confirm the exact model, ratings and approvals for your switchboard or enclosure before ordering.

Quantity (units)

Your configuration (optional)

Project Supplies specification sheet

Confirm the specification and quotation before ordering.

Product introduction

Terminal blocks

LEIPOLE JDIK 1.5 is a standard feed-through terminal block with screw connection, designed for DIN rail mounting. It is applied to industrial control and low-voltage power distribution circuits, with qualified insulating housing and conductive parts to ensure stable electrical connection in regular industrial environments. Key Features & Advantages Adopts standard screw clamping connection for reliable wire fixing Made of flame retardant insulating material for daily electrical safety Standard DIN rail installation, easy for assembly and combination Compact structure, suitable for dense cabinet wiring layout Stable conductive performance, suitable for long-term continuous operation Typical ….

Key data: certification CE, CQC; zack strip ZB5; size T6.2×H55.5×W56; rated current/rated voltage 26A/250V.

Every order starts with an RFQ: we confirm the exact variant, options, lead time and commercial terms in an itemised quotation before anything is ordered.

CertificationCE, CQC

Zack StripZB5

SizeT6.2×H55.5×W56

Rated Current/Rated Voltage26A/250V

Cross Section0.2~4mm²

ModelJDIK 1.5

Flammability ClassUL 94 V0

Connection StandardIEC 60947-7-1
