LEIPOLELEIPOLE F2E190-230-DP DP Series Filter Fan, IP55, 230V, 310x270x130mm LP-F2E190-230-DP
Enclosure coolingHover to zoom

LEIPOLE · Enclosure cooling

LEIPOLE F2E190-230-DP DP Series Filter Fan, IP55, 230V, 310x270x130mm

SKULP-F2E190-230-DP

LEIPOLE Enclosure cooling · Control panel components. Specified, quoted and supplied by Project Supplies for commercial projects.

Rated voltage (V / Hz)230/50/60
Air flow, free blowing570/620 m³/h
Rated current (A)0.33/0.32
Power (W)69/73
Price on requestQuoted for your configuration and quantity.
Technical clarificationSpecifications and certification marks are as published by LEIPOLE Singapore and are not independently verified. Confirm the exact model, ratings and approvals for your switchboard or enclosure before ordering.
Project Supplies specification sheet

Confirm the specification and quotation before ordering.

Product introduction

Enclosure cooling

LEIPOLE F2E190-230-DP belongs to the DP series top-mounted filter fan, engineered for high-airflow thermal management of large-scale industrial electrical enclosures. It adopts integrated top ventilation structure to realize efficient internal heat dissipation, dust isolation and stable environmental control for enclosed electrical cabinets. Core Product Features Dual optional housing color finishes: RAL7035 and RAL7032, adaptable to diversified industrial cabinet appearance matching demands IP55 ingress protection rating, providing robust defense against dust intrusion and low-pressure water splash for internal enclosure components Standard overall dimension of 310x270x130mm, with unified ….

Key data: rated voltage 230/50/60; air flow, free blowing 570/620 m³/h; rated current 0.33/0.32; power 69/73.

Every order starts with an RFQ: we confirm the exact variant, options, lead time and commercial terms in an itemised quotation before anything is ordered.

Rated voltage (V / Hz)230/50/60

Air flow, free blowing570/620 m³/h

Rated current (A)0.33/0.32

Power (W)69/73

ModelF2E190-230-DP

Order number2017.004/2017.011

Motor modelM2E09201-AF

Axial FanElectric capacitance

Specifications

The technical details.

Download specification sheet
Category
Enclosure cooling
Model
F2E190-230-DP
Order number
2017.004/2017.011
Motor model
M2E09201-AF
Rated voltage (V / Hz)
230/50/60
Air flow, free blowing
570/620 m³/h
Axial Fan
Electric capacitance
Rated current (A)
0.33/0.32
Power (W)
69/73
Noise level (dB)
62/64
Operating temperature range
-10°C to +55°C
Remarks
The number of air inlet filter, size according to the specific circumstances.

Documents

Specification sheet & source.

Project Supplies specification sheet

LP-F2E190-230-DP

Product image, key data, the full specification and document control — laid out for project submittals.

PDF · A4Reviewed 2026-10-06LEIPOLE
Open specification sheet

Technical source

LEIPOLE

Checked 2026-10-06. Manufacturer values are reference specifications; confirm the exact variant and installation requirements before approval.
