InventronicsInventronics OTi DALI 24V constant-voltage LED driver series INV-OTI-DALI-24V
Constant-voltage LED driversHover to zoom

Inventronics · Constant-voltage LED drivers

Inventronics OTi DALI 24V constant-voltage LED driver series

SKUINV-OTI-DALI-24V

Inventronics Constant-voltage LED drivers · Power, drivers & controls. Specified, quoted and supplied by Project Supplies for commercial projects.

Output power30–160 W
Dimming range0.1 ~ 100 % (for 50-80-160W) or 1 ~ 100 % (for 30W)
IP rating (as published)IP20
Line frequency0 Hz | 50 Hz | 60 Hz
Price on requestQuoted for your configuration and quantity.
Technical clarificationCompiled from the supplied Inventronics Lighting Systems product overview catalogue (page 198). Merged table cells are left blank as printed. Ratings and certifications are supplier claims; confirm the exact model datasheet before ordering.
Project Supplies specification sheet

Confirm the specification and quotation before ordering.

Product introduction

Constant-voltage LED drivers

Dimmable via Touch DIM; Available as single-channel or multi-channel with DT6 and; DT8 in one device.

Key data: output power 30–160 W; dimming range 0.1 ~ 100 % (for 50-80-160W) or 1 ~ 100 % (for 30W); ip rating IP20; line frequency 0 Hz | 50 Hz | 60 Hz.

This record covers 7 catalogue models; the full model table is listed below and in the specification sheet. Tell us the exact model in your RFQ.

Every order starts with an RFQ: we confirm the exact variant, options, lead time and commercial terms in an itemised quotation before anything is ordered.

Output power30–160 W

Dimming range0.1 ~ 100 % (for 50-80-160W) or 1 ~ 100 % (for 30W)

IP rating (as published)IP20

Line frequency0 Hz | 50 Hz | 60 Hz

Specifications

The technical details.

Download specification sheet
Product type
Constant-voltage LED driver
Applications (catalogue)
Retail, hospitality & commercial, Architectural, signage & non-lighting
Output power
30–160 W
Dimming range
0.1 ~ 100 % (for 50-80-160W) or 1 ~ 100 % (for 30W)
Line frequency
0 Hz | 50 Hz | 60 Hz
IP rating (as published)
IP20
Key features
Dimmable via Touch DIM ; Available as single-channel or multi-channel with DT6 and ; DT8 in one device ; Dimming range: 0.1 ~ 100 % (for 50-80-160W) or 1 ~ 100 % (for 30W) ; D ; Line frequency: 0 Hz | 50 Hz | 60 Hz
Models
OTi DALI 30/220-240/24 1CH, OTi DALI 50/220-240/24 1CH G3, OTi DALI 50/220-240/24 4CH DT6/8 G3, OTi DALI 80/220-240/24 1CH G3, OTi DALI 80/220-240/24 4CH DT6/8 G3, OTi DALI 160/220-240/24 1CH G3, OTi DALI 160/220-240/ 24 2CH DT6/8 G3
Model count
7

Models & variants

Choose the exact model.

Values as published by Inventronics. Name the exact model or variant in your RFQ.

EANProduct nameOutput power (W)Output current (mA)Output voltage (V)EfficiencyDimensions (mm)
6937186115119OTi DALI 30/220-240/24 1CH30not relevant24.288%103 x 67 x 29.5
6977770431881OTi DALI 50/220-240/24 1CH G350not relevant24.292%346 x 32 x 22
6977770431966OTi DALI 50/220-240/24 4CH DT6/8 G350not relevant24.292%346 x 32 x 22
6977770431867OTi DALI 80/220-240/24 1CH G380not relevant24.293%346 x 32 x 22
6977770431942OTi DALI 80/220-240/24 4CH DT6/8 G380not relevant24.293%346 x 32 x 22
6977770431904OTi DALI 160/220-240/24 1CH G3160not relevant24.293%300 x 50 x 35
6977770431928OTi DALI 160/220-240/ 24 2CH DT6/8 G3160not relevant24.293%300 x 50 x 35

Documents

Specification sheet & source.

Project Supplies specification sheet

INV-OTI-DALI-24V

Product image, key data, the full specification, the model table and document control — laid out for project submittals.

PDF · A4Reviewed 2026-10-05Inventronics
Open specification sheet

Technical source

Inventronics

Checked 2026-10-05. Manufacturer values are reference specifications; confirm the exact variant and installation requirements before approval.
