CESPZone 1 Explosion Proof LED Linear Light - ATEX IECEx - 360W 400W CESP-EX-LN-02-80-271
Ex linear & fluorescent replacementHover to zoom

CESP · Ex linear & fluorescent replacement

Zone 1 Explosion Proof LED Linear Light - ATEX IECEx - 360W 400W

SKUCESP-EX-LN-02-80-271

CESP Ex linear & fluorescent replacement · Explosion-proof lighting. Specified, quoted and supplied by Project Supplies for commercial projects.

Hazardous-area schemeIECEx / ATEX (zones per Ex marking)
Power360W / 400W
Input voltageAC100-240/277V, 50/60Hz
Luminous flux46800LM / 52000LM
Price on requestQuoted for your configuration and quantity.
Technical clarificationHazardous-area ratings, Ex markings and certificate references are as published by CESP and are not independently verified. Confirm the certificate, marking and conditions of use for the exact model against the area classification before ordering. In Australia, hazardous-area equipment normally requires IECEx or ANZEx certification, and installation and inspection must follow AS/NZS 60079 by competent persons.
Project Supplies specification sheet

Confirm the specification and quotation before ordering.

Product introduction

Ex linear & fluorescent replacement

Explosion-proof linear & fluorescent replacement · IECEx / ATEX (zones per Ex marking). 360W / 400W · 46800LM / 52000LM · IP66 · -40°C to + 50°C.

Key data: hazardous-area scheme IECEx / ATEX (zones per Ex marking); power 360W / 400W; input voltage AC100-240/277V, 50/60Hz; luminous flux 46800LM / 52000LM.

Every order starts with an RFQ: we confirm the exact variant, options, lead time and commercial terms in an itemised quotation before anything is ordered.

Hazardous-area schemeIECEx / ATEX (zones per Ex marking)

Power360W / 400W

Input voltageAC100-240/277V, 50/60Hz

Luminous flux46800LM / 52000LM

Luminous efficacy120 - 140lm/W

Colour temperature3000K/4000K/5000K/5700K/6500K

IP ratingIP66

Power factor0.97

Specifications

The technical details.

Download specification sheet
Hazardous-area scheme
IECEx / ATEX (zones per Ex marking)
Collection
Ex linear & fluorescent replacement
Series
CES-EX-LN-02-80
Power
360W / 400W
Input voltage
AC100-240/277V, 50/60Hz
Luminous flux
46800LM / 52000LM
Luminous efficacy
120 - 140lm/W
Colour temperature
3000K/4000K/5000K/5700K/6500K
IP rating
IP66
Operating temperature
-40°C to + 50°C
Power factor
0.97
LED package
3030
LED driver
Meanwell HLG series
Housing
Aluminum alloy (ADC12 and 6063)
Lens
Tempered glass
Cable entry
M25 X 1.5
Dimensions
564*202*112mm (Single Fixture)
Weight
10.6KG (Single Fixture)，Total 31.8KG
Warranty (as published)
5 years warranty
Ex marking (as published)
Ex ec IIC T *Gc; Ex tb IIIC T *°C Db; II 3G Ex ec IIC T*Gc; II 2D Ex tb IIIC T*Db
Certificate reference (as published)
IECEx Certificate No. : IECEx UL 22.0091X; IECEx Certificate No. : ATEX Certificate No.: UL 22 ATEX 2543X, UL 22 ATEX 2544X

Documents

Specification sheet & source.

Project Supplies specification sheet

CESP-EX-LN-02-80-271

Product image, key data, the full specification and document control — laid out for project submittals.

PDF · A4Reviewed 2026-10-05CESP
Open specification sheet

Technical source

CESP

Checked 2026-10-05. Manufacturer values are reference specifications; confirm the exact variant and installation requirements before approval.

View source
Certificate check We obtain the certificate for the exact model before quoting.Ex accessories Cable glands and junction boxes sourced on request.Project support Documentation and delivery coordinated with your Ex contractor.
